Vertex Vertical TwoTier Commercial Fountain

Fountain Features

• Floating lake fountain designed for large-scale commercial application.

• Available in 2 HP, 3 HP, and 5 HP.

• Suggested LED Lighting Packages:


• 2 lights for 2 HP and 3 HP
• 3 lights for 5 HP

Warranty Coverage

All Vertex floating lake fountain designs go through extensive production quality control processes as well as continued testing after installation to ensure your product lasts.

• Display heads: 4-years

• Pumps and motors: 4-years

• LED Lighting: 2-years

• Control Panel: 1-year

Description

The Vertex Vertical Pond Fountain models were developed using the same strict standards as our larger models and are covered under the same warranty program with 4 year coverage for display heads, pumps and motors, 2 years on LED lighting and 1 year for the control panel.

• Competitively priced

• Quicker installations with a self leveling design

• Smaller profile/lower weight makes handling easier and reduces freight costs

• Lower maintenance costs with no oils, 0-rings or seals to change

Quality and Durability

• Rugged, commercial grade construction stainless steel turbine pumps/motors

• Precision machined brass/stainless steel display nozzles with defined patterns

• Customize your displays and/or controls

• Stainless steel LED lights

Nozzles

• Precision stainless steel nozzles.

Pumps/Motors

• High performance turbine pump/motor assembly

• Stainless steel construction

• Water cooled: no oils, seals or o-rings to replace

• 4 year warranty

Flotation

• Rotocast polypropylene with UV inhibitors for long life

• Individual leveling compartments for exact adjustments

• 4 year warranty

Control Panel

• UL listed per National Electrical Code

• Weatherproof steel enclosures

Submersible Light Fixtures

• 43Watt, 120V clear, stainless steel LED light fixtures with tempered lens and neoprene gaskets, mounting brackets and fastenings of stainless steel

• Energy efficient LED, 140 lumens

• Stainless steel housing

• 2 year warranty

Cables

(NOT INCLUDED IN LISTED PRICE)

- Call for price on cable

• STW-A rated

• 4 year warranty

Minimum Water Depth

Electrical Specs

Documentation

Vertex Vertical Pond Fountains Brochure

Vertex Vertical TwoTier System Specifications

Vertex Vertical Fountain Manual
